CTS Battery Multi-Compartment Fuel Tank Alarm

CTS Battery Multi-Compartment Fuel Tank Alarm
CTS Battery Multi-Compartment Fuel Tank Alarm CTS Battery Multi-Compartment Fuel Tank Alarm CTS Battery Multi-Compartment Fuel Tank Alarm CTS Battery Multi-Compartment Fuel Tank Alarm
Product Code: SWS1040
Availability: In Stock
Prices from: £56.98 (inc VAT)
Ex VAT: £47.48

Delivery

Order total Delivery
Under £30.00 (+VAT) £20.00
Over £30.00 (+VAT) £15.00

Available Options


* Model:

Qty:     - OR -   Add to Wish List
Add to Compare

The CTS Battery Operated Multi-Compartment Fuel Tank Alarm system has three functions; to detect and warn of a fuel storage tank overfill, a high/low liquid level and a bund leak. If the tank level alarm identifies that any of these states have occurred, the zone in question will illuminate on the alarm’s screen, and a loud siren and flashing red light will go off. When its battery is low, this level bund alarm will sound a single beep every minute to alert the user of this.

Thanks to being battery powered, these fuel tank alarms are designed to be installed on isolated or portable systems, and each zone can be configured allowing the alarm to be customised by the installer. Options are available that come with three relays, allowing additional equipment to be connected to the tank level alarm such as larger alarm systems or building management systems for remote monitoring.

If you need a tank level alarm for a fluid other than diesel or light oil, also available are a water and chemical alarm probe, and a high viscosity oil tank level probe – which is also suitable for AdBlue as well as high viscosity oils. Please see the accessories table.

Please note: Codes SWS1000 and SWS1001 do not come complete with probes. Please view the accessories table to select the combination you need. All cables must be free of electrical noise.

Features of the CTS Battery Multi-Zone Fuel Tank Level Alarm:

  • For any combination of high, low, bund
  • Weatherproof IP55 rated box
  • LED zone lights up to indicate the issue
  • Beeping alert of low battery
  • Alarm siren
  • Test and alarm mute functions
  • 6 x 9v AA Batteries
  • Option available with 3 relays
  • Options with probe/s available - see table
  • SWS2000 and SWS2001 not supplied with probes - select from accessories table
  • 45m max probe length
Code Product Description Price (excl VAT)
SWS1001 CTS Battery Multi-Compartment Fuel Tank Alarm Box Only c/w 3 relays Box only - select probes from accessories table
6 x AA Batteries
Red warning LED
Sounder
3 x Relays (C,NO,NC @ 230v 8A)
£231.56
SWS1000 CTS Battery Multi-Compartment Fuel Tank Alarm Box Only Box only - select probes from accessories table
6 x AA Batteries
Red warning LED
Sounder
£205.92
SWS1035/2 Double Fuel Tank Alarm Probe - For high and low level Alerts - High/low, high/high, low/low
Cable - 2 x 5m PVC
Temperature - -20°c - +80°c
Connection - 1 1/2" F BSP brass cap
2 x Grommet
For diesel, fuels, light oils and water
£91.88
SWS1038 High Viscosity Fluid Tank Level Alarm Probe Alerts - High and Low
Cable - 5m PVC
Temperature - 0°c - +60°c
Connection - 1 1/2" F BSP Plastic Cap
For viscous fluids and waste oils
£93.68
SWS1040 Water & Chemical Tank Level Alarm Probe Alerts - High or Low
Cable - 5m PVC
Temperature - 20°c - +80°c
Connection - 1 1/2" F BSP Polyethylene Cap
£47.48
SWS2011 CTS Battery Multi-Compartment Fuel Tank Alarm Box c/w Single Probe & 3 Relays Alarm Box c/w Single Probe
6 x AA Batteries
Red warning LED
Sounder
3 x Relays (C,NO,NC @ 230v 8A)
£277.00
SWS2012 CTS Battery Multi-Compartment Fuel Tank Alarm Box c/w Single Probe, Double Probe & 3 Relays Alarm Box c/w Single & Double Probes
6 x AA Batteries
Red warning LED
Sounder
3 x Relays (C,NO,NC @ 230v 8A)
£341.04
SWS1038AB AdBlue Tank Level Alarm Probe Alerts - High and Low
Cable - 5m PVC
Temperature - 0°c - +60°c
Connection - 1 1/2" F BSP Plastic Cap
For AdBlue
£80.88

Accessories

Code Accessory Price (excl VAT)
AGR-SWS1035 Single Fuel Probe – for leak detection if drip tray is installed
£38.45
SWS1036 Plastic Tank Kit - For Single Probe Kit for using a probe on a plastic rather than steel tank Steel, flat, round plate 1 x Grommet
£9.56
SWS1037 Plastic Tank Kit - For Double Probe
Kit for use on a plastic rather than steel tank
Steel, flat, round plate
2 x Grommet
£12.60
SWS1009 Extra Alarm Cable Per Metre Per Metre
£1.96
SWS1035 Single Fuel Probe – for leak detection if drip tray is installed
£48.88
